Product Details:
|
| Model Number: | TU | Application: | Applied To TFT-LCD,AMOLED Glass Panel And OGS Glass |
|---|---|---|---|
| Tickness: | 0.65mm | Product Brand: | WORLDIA |
| Type: | Scribing Wheel | Name: | Diamond Scribing Wheel |
| High Light: | TU Type Diamond Scribing Wheel,0.65mm Thick Scribing Wheel,Scribing Wheel For OGS Glass |
||
Diamond scribing wheels TY Type used for TFT-LCD, AMOLED glass panel, and LCD glass
WORLDIA
WORLDIA pays special attention to the making of Standard Super Hard Cutting Tools.
And we have made a tremendous amount of technical innovations in the design and the manufacturing
of PCBN/PCD/CVD inserts and related products.
INTRODUCTION
As a tool for glass cutting, the diamond scribing wheel is the primary factor to decide the cutting quality
of the glass. The Worldia diamond scribing wheel features stable function, sharp cutting edge,
precise cutting angle, and precise roundness and thickness of the bore.
These features guarantee the excellent cutting quality.
FEATURES
|
|
APPLICATION
Application:
Cutting mid and small TFT-LCD, AMOLED glasses of thickness above 0.2mm, and Tempered
OGS Glasses with DOL of 45um which requires a strong bending requirement.
SPECIFICATION
| OD (mm ) | Angle(°) | Thickness(mm) | ID(mm) | Teeth Qty | Teeth Depth (μm) |
| 1.80 | 100~140 | 0.65 | 0.80 | 140/160/180/230 | 1→10 |
| 2.00 | 100~140 | 0.65 | 0.80 | 140/160/180/230 | 1→10 |
| 2.50 | 100~140 | 0.65 | 0.80 | 220/240/260/280/350 | 1→10 |
| 3.00 | 100~140 | 0.65 | 0.80 | 180/200/220/230/290 | 1→10 |
| Remarks | Interval of 5° | Interval of 10° |
