Economic Composite Diamond Scribing Wheel Automobile PV Decorative Glass Cutting Wheel

Economic Composite Diamond Scribing Wheel Automobile PV Decorative Glass Cutting Wheel
Economic Composite Diamond Scribing Wheel Automobile PV Decorative Glass Cutting Wheel Economic Composite Diamond Scribing Wheel Automobile PV Decorative Glass Cutting Wheel

Large Image :  Economic Composite Diamond Scribing Wheel Automobile PV Decorative Glass Cutting Wheel

Product Details:
Place of Origin: Beijing, China
Brand Name: WORLDIA
Model Number: HD
Payment & Shipping Terms:
Minimum Order Quantity: 10 pieces
Price: 1/Piece $10
Packaging Details: Plastic case
Delivery Time: 2-3 days
Payment Terms: L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability: 50000 Piece/Pieces per Month
Contact Now

Economic Composite Diamond Scribing Wheel Automobile PV Decorative Glass Cutting Wheel

Description
Product Brand: WORLDIA Type: Scribing Wheel
Name: Composite Diamond Scribing Wheel Material: Advanced Diamond Composite Material
Model Number: HD Advantage: Economic
Hardness: 9000-10000HV Usage: Glass Cutting
OEM: Acceptd Application: Applied To Cutting Of OGS, STN, TP, Panel And ITO Conductive Glass. Applied To Cutting Of Decorative Mirror, Architectural Glass, Automobile Glass.
Highlight:

Composite Diamond Scribing Wheel

,

Economic Diamond Scribing Wheel

,

PV Decorative Glass Cutting Wheel



Economic Composite diamond scribing wheel for automobile PV Decorative glass cutting



FEATURE





  • The hardness of HD diamond scribing wheel is as high as 90000HV and its cutting edge is relatively sharp. It has the characteristics of good cutting line continuity, vertical section and strong penetration.
  • The HD diamond scribing wheel can keep the glass cutting section with high flatness, which effectively reduces the grinding cost. The cutting edge is processed by a special technology, which helps to avoid the accidents of slipping during the high-speed rotation and result in the lower frequency of quality abnormity in the cutting process.
  • Compared with diamond toothed scribing wheels, HD scribing wheel is relatively low in cost. Because of the excellent wear resistance, the service life is much higher than that of ordinary carbide cutting wheels. Therefore, it owns higher quality and lower cost performance, and can be positioned in the market to the intermediate product between carbide scribing wheel and diamond toothed.



ADVANTAGE

  • Long service life
 This scribing wheel is made by advanced composite material, which has three-times long service life than carbide cutting wheels
  • Better effect
 1.Cutting Line: WIth better continuity, smooth processing,strong penetration
2.Cutting section: With high flatness,reduce grinding cost
3.Times effiency



APPLICATION



Architectural Glass Automobile Glass
HD DIAMOND SCRIBING WHEELS HD DIAMOND SCRIBING WHEELS
Small size, big power Small size, big power
Long service life, better cutting effect Long service life, better cutting effect
Processing building glass, showing the beauty of cutting Processing automobile glass, viewing a different world

PV glass Decorative Mirror
HD DIAMOND SCRIBING WHEELS HD DIAMOND SCRIBING WHEELS
Small size, big power Small size, big power
Long service life, better cutting effect Long service life, better cutting effect
Processing PV glass plate, promoting green new energy Processing Makeup mirror glass, details highlight quality



SPECFICATION



Glass Thickness Specification Recommended Angle Range Remark
2-4mm 4.2*1.4*1.1*θ° 130°≤θ≤135° Customized
product is also available!
4-6mm 4.2*1.4*1.1*θ° 135°≤θ≤145°
6-8mm 5.6*1.4*1.1*θ° 145°≤θ≤150°
8-15mm 5.6*1.4*1.1*θ° 150°≤θ≤160°



OTHER TYPES

Economic Composite Diamond Scribing Wheel Automobile PV Decorative Glass Cutting Wheel 0



PACKING DETAIL



Size 5.5(L)CM*4(W)CM*1(H)CM
Weight 0.025KG
Delivery 2~3 days



Economic Composite Diamond Scribing Wheel Automobile PV Decorative Glass Cutting Wheel 1
